Photographs show the package and laser marking of the device. Mechanical dimensions, pin-out and the applicable temperature grade are confirmed against the manufacturer's current datasheet — ask for it with your quotation.
Product information
| Ordering code | FCS030T |
|---|---|
| Product line | FPGA & Programmable Logic |
| Form | Discrete device |
| Process node | 28 nm |
| Logic cells | 326K |
| DSP slices | 840 |
| BRAM capacity | 16 Mb |
| Clock management tiles | 10 |
| SerDes | 16 lanes @ 12.5 Gb/s |
| PCIe | 1 × (supports up to x8 Gen2) |
| Max user I/O | 500 |
| Core voltage | 0.9 / 1.0 V |
| Package size | 31 × 31 mm (FFG900) |
| Quality grade | Industrial · Wide-Temperature Industrial |
| Note | Available in FFG900 and FFG676 packages, and as bare die. |
Ordering information
| Ordering code | Package | Package size | Max user I/O | Selection Support |
|---|---|---|---|---|
FCS030T-FFG900 | FFG900 | 31 × 31 mm | 500 | XC7K325T-FFG900 This does not imply direct replacement or compatibility. |
FCS030T-FFG676 | FFG676 | 27 × 27 mm | 400 | XC7K325T-FFG676 This does not imply direct replacement or compatibility. |
All listed devices are offered in Industrial · Wide-Temperature Industrial grades and are also available as bare dies. Availability, package options and grade suffix are confirmed in the written quotation.
pengrui
FCS030T FPGA
FCS030T
326K logic cell FPGA in 28nm with 16 SerDes lanes at 12.5 Gb/s and PCIe Gen2 x8.
Independent Supply
This product is offered by Pengrui Technology through independent sourcing channels. We are not an authorized distributor or agent of the manufacturer.
Availability, product condition, date code, packaging, supporting documentation and warranty terms are subject to confirmation in our written quotation.
Add this part to your quote list to request several line items together, or send the ordering code directly. Tell us the grade you need for FPGA and SoC devices.
- Industrial and wide-temperature industrial grades available for FPGA and SoC
- Technical selection support from the same team that quotes you
- PCB fabrication available for the same project through our partner network
